※ Other Materials on Special Order.
Size in inches
| Shaft Dia | D1 | D2 | L1 | L2 |
|---|---|---|---|---|
| 3/8 | .875 | 1 1/16 | 1 3/16 | 5/16 |
| 1/2 | 1.000 | 1 3/16 | 1 3/16 | 5/16 |
| 5/8 | 1.250 | 1 11/32 | 1 5/16 | 13/32 |
| 11/16 | 1.312 | 1 13/32 | 1 5/16 | 13/32 |
| 3/4 | 1.375 | 1 15/32 | 1 5/16 | 13/32 |
| 13/16 | 1.437 | 1 9/16 | 1 3/8 | 13/32 |
| 7/8 | 1.500 | 1 21/32 | 1 3/8 | 13/32 |
| 15/16 | 1.562 | 1 11/16 | 1 9/16 | 7/16 |
| 1 | 1.625 | 1 3/4 | 1 9/16 | 7/16 |
| 1 1/16 | 1.687 | 1 13/16 | 1 5/8 | 7/16 |
| 1 1/8 | 1.750 | 1 7/8 | 1 5/8 | 7/16 |
| 1 3/16 | 1.812 | 1 15/16 | 1 5/8 | 7/16 |
| 1 1/4 | 1.875 | 2 | 1 5/8 | 7/16 |
| 1 3/8 | 2.000 | 2 1/8 | 1 11/16 | 7/16 |
| 1 7/16 | 2.062 | 2 3/16 | 1 11/16 | 7/16 |
| 1 1/2 | 2.215 | 2 1/4 | 1 11/16 | 7/16 |
| 1 5/8 | 2.375 | 2 1/2 | 2 | 1/2 |
| 1 3/4 | 2.500 | 2 5/8 | 2 | 1/2 |
| 1 7/8 | 2.625 | 2 3/4 | 2 1/8 | 1/2 |
| 1 15/16 | 2.687 | 2 13/16 | 2 1/8 | 1/2 |
| 2 | 2.750 | 2 15/16 | 2 1/8 | 1/2 |
| 2 1/8 | 3.000 | 3 1/8 | 2 3/8 | 9/16 |
